2023 Suzuki DR-Z 400SM Single-Cylinder 398
Price:
$7,749.00
- Year: 2023
- Make: Suzuki
- Model: DR-Z 400SM
- Condition: New
Engine Type: 4-stroke, single cylinder, DOHC
Displacement: 398cc
Bore and Stroke: 3.54 in. x 2.44 in. (90.0 mm x 62.6 mm)
Cooling: Liquid
Compression Ratio: 11.3:1
Fuel System: Mikuni BSR36, single carburetor
Ignition: Electronic ignition (CDI)
Transmission: 5-speed constant mesh
Final Drive: Chain, RK520KZ0, 110 links
Front Suspension: Inverted telescopic, coil spring, oil damped, adjustable damping force
Rear Suspension: Link type, coil spring, oil damped, adjustable spring preload and damping force
Front Brakes: Disc brake, single floating rotor
Rear Brakes: Disc brake, single rotor
Front Tire: 120/70 R17 M/C 58H, tube type
Rear Tire: 140/70 R17 M/C 66H, tube type
Wheelbase: 57.5 in. (1460 mm)
Seat Height: 35.0 in. (890 mm)
Fuel Capacity: 2.6 US gal. (10.0 L)
Dry Weight: Curb Weight: 322 lb. (146 kg)
Colors: Grand Blue No. 2 & Solid Black, Solid Special White No. 2
Displacement: 398cc
Bore and Stroke: 3.54 in. x 2.44 in. (90.0 mm x 62.6 mm)
Cooling: Liquid
Compression Ratio: 11.3:1
Fuel System: Mikuni BSR36, single carburetor
Ignition: Electronic ignition (CDI)
Transmission: 5-speed constant mesh
Final Drive: Chain, RK520KZ0, 110 links
Front Suspension: Inverted telescopic, coil spring, oil damped, adjustable damping force
Rear Suspension: Link type, coil spring, oil damped, adjustable spring preload and damping force
Front Brakes: Disc brake, single floating rotor
Rear Brakes: Disc brake, single rotor
Front Tire: 120/70 R17 M/C 58H, tube type
Rear Tire: 140/70 R17 M/C 66H, tube type
Wheelbase: 57.5 in. (1460 mm)
Seat Height: 35.0 in. (890 mm)
Fuel Capacity: 2.6 US gal. (10.0 L)
Dry Weight: Curb Weight: 322 lb. (146 kg)
Colors: Grand Blue No. 2 & Solid Black, Solid Special White No. 2
Basic Information
- Year: 2023
- Make: Suzuki
- Model: DR-Z 400SM
- Condition: New
- Type: Standard
- Title: Clean
- Color: BLUE
Brakes
- Front Brake: Hydraulic Disc
- Front Brake Diameter (in): 11.8
- Front Brake Diameter (mm): 300
- Rear Brake: Hydraulic Disc
- Rear Brake Diameter (in): 9.5
- Rear Brake Diameter (mm): 240
Chassis & Suspension
- Frame: Aluminum / Steel
- Front Adjustable Fork Pre-Load
- Front Adjustable Rebound Damping
- Front Suspension Brand Name: Showa
- Front Suspension Type: Inverted Fork
- Front Travel (in): 10.2
- Front Travel (mm): 260
- Number Rear Shock Absorbers: 1
- Rear Adjustable Rebound Damping
- Rear Adjustable Shock / Spring Pre-Load
- Rear Suspension Material: Aluminum
- Rear Suspension Type: Twin Sided Swing Arm
- Rear Travel (in): 10.9
- Rear Travel (mm): 276
Comfort
- Digital Instrumentation
- Trip Odometer
Drivetrain
- Number Of Speeds: 5
- Primary Drive (Rear Wheel): Chain
- Transmission: Manual
- Transmission Final Drive Ratio: 2.733
- Transmission Gear Ratio (1): 2.285
- Transmission Gear Ratio (2): 1.733
- Transmission Gear Ratio (3): 1.375
- Transmission Gear Ratio (4): 1.09
- Transmission Gear Ratio (5): 0.863
Engine
- Bore (in): 3.54
- Bore (mm): 90
- Carburetor Size (mm): 36
- Carburetion Brand: Mikuni
- Carburetion Type: Carburetor
- Carburetor
- Compression Ratio: 11.3:1
- Cooling System: Liquid / Air
- Cylinders: 1
- Engine Size (cc): 398
- Engine Size (ci): 24.3
- Engine Stroke: 4-Stroke
- Engine Type: Single-Cylinder
- Fuel Capacity (gal): 2.6
- Fuel Requirements: Regular
- Number Of Carburetors: 1
- Starter: Electric
- Stroke (in): 2.44
- Stroke (mm): 62.6
- Valve Configuration: DOHC
- Valves: 4
- Valves Per Cylinder: 4
Other Information
- Decal Kit
- Engine Case Guard
- Exhaust Guard
- Exterior Covers
- Exterior Guards
- Foot Pegs
- Foot Peg Location: Driver and Passenger
- Fork Guards
- Front Fender
- Hand Grips
- Heel Guards
- Side Cover
- Rear Fender
- Stand
- Stand Type: Kick
- Tail Bag
Safety
- Headlight
- Headlight Type: Halogen
- Rearview Mirrors
Specifications
- Body Material: Plastic
- Front Tire (Full Spec): Dunlop 120/70 R17 M/C 58H
- Front Tire (Inches): 17
- Front Tire Aspect Ratio: 70
- Front Tire Speed Rating: H
- Front Tire Width: 120
- Front Wheel Width (in): 3.5
- Fuel Capacity (liters): 10
- Ground Clearance (in): 10.2
- Ground Clearance (mm): 260
- Height (inches): 47
- Height (mm): 1200
- Length (inches): 87
- Length (mm): 2225
- Rear Tire (Full Spec): Dunlop 140/70 R17 M/C 66H
- Rear Tire (Inches): 17
- Rear Tire Aspect Ratio: 70
- Rear Tire Speed Rating: H
- Rear Tire Width: 140
- Rear Wheel Width (in): 4.5
- Seat Height (inches): 35
- Tube / Tubeless: Tubed
- Turning Radius (ft): 8.5
- Wet Weight (kg): 146
- Wet Weight (lbs): 321
- Wheelbase (in): 57.5
- Wheelbase (mm): 1460
- Wheels Composition: Aluminum
- Width (inches): 33
- Width (mm): 855
- Speedometer
