2022 KTM SX 85 (17/14) Single-Cylinder 84.9 VBKMRC235NM021991 - XTREME MACHINES

2022 KTM 85 SX 17/14

THE NEXT STEP TO GREATNESS

The 2022 KTM 85 SX offers a real taste of the big leagues by giving young racers a real-world big bike experience with an impressive list of componentry and blistering performance. This is also thanks to its lightweight, high-quality frame which houses a compact rocket ship of an engine, delivering unrivaled rideability, providing the ultimate platform for aspiring racers.

Features may include:

01. ENGINE & EXHAUST

ENGINE

It took extreme levels of ingenuity to fit the race-winning formula of KTM's bigger 2-strokes into a compact 85 cc engine. A special manufacturing process is used and provides impressive weight savings without sacrificing strength or durability. The super compact power plant is fitted with a 6-speed gear box and delivers class-leading power and rideability throughout the entire rev range. The power valve plays a key role in tailoring power delivery to suit track conditions and rider ability, ensuring that the only rider surprised by the incredible performance is the competition.

02. CHASSIS

FRAME

The frame on the KTM 85 SX is a scaled-down version of the championship-proven full-size frames. It is professionally crafted using hydroformed chromium molybdenum steel tubes that are robot welded, ensuring the highest levels of consistent quality. The flex characteristics have been specifically tailored for easy handling and optimal comfort, while working in perfect harmony with the suspension, to ensure excellent agility and high-speed stability. For 2020, the frames feature highly durable orange powder coating and come with standard frame protectors.

03. ERGONOMICS & COMFORT

HANDLEBAR

The KTM 85 SX features a strong, lightweight, tapered aluminum handlebar, with a specifically shaped bend to suit the overall ergonomics. Additionally, the bike comes standard with ODI lock-on grips, which include a vulcanized grip on the right side and a lock-on grip on the left that does not require glue or wire for mounting.

04. BODYWORK & GRAPHICS

DECALS

The bodywork is fittingly finished off with aggressive, modern graphics, leaving the competition in no doubt of a rider's race-winning intentions.

Basic Information

Year: 2022
Make: KTM
Model: SX
Trim: 85 (17/14)
Stock Number: KTM021991
VIN: VBKMRC235NM021991
Condition: Used
Type: Off-Road
Mileage: 20
Title: Clean
Color: ORANGE

Brakes

Brake Brand Name: Formula
Front Brake: Hydraulic Disc
Front Brake Diameter (in): 9.4
Front Brake Diameter (mm): 240
Rear Brake: Hydraulic Disc
Rear Brake Diameter (in): 8.7
Rear Brake Diameter (mm): 220

Chassis & Suspension

Frame: Chromium Molybdenum
Front Adjustable Fork Pre-Load
Front Adjustable Rebound Damping
Front Suspension Brand Name: WP XACT
Front Suspension Size (in): 1.7
Front Suspension Size (mm): 43
Front Suspension Type: Inverted Fork
Front Travel (in): 10.9
Front Travel (mm): 278
Number Rear Shock Absorbers: 1
Rear Adjustable Rebound Damping
Rear Adjustable Shock / Spring Pre-Load
Rear Suspension Brand Name: WP XACT
Rear Suspension Material: Aluminum
Rear Suspension Type: Twin Sided Swing Arm
Rear Travel (in): 12
Rear Travel (mm): 305

Comfort

Adjustable Handlebars

Drivetrain

Number Of Speeds: 6
Primary Drive (Rear Wheel): Chain
Transmission: Manual
Primary Drive (Engine / Transmission): Gear
Transmission Final Drive Ratio: 3.29
Transmission Gear Ratio (1): 2.64
Transmission Gear Ratio (2): 2
Transmission Gear Ratio (3): 1.63
Transmission Gear Ratio (4): 1.37
Transmission Gear Ratio (5): 1.19
Transmission Gear Ratio (6): 1.05

Engine

Bore (in): 1.85
Bore (mm): 47
Carburetor Size (mm): 38
Carburetion Brand: Mikuni
Carburetion Type: Carburetor
Carburetor
Cooling System: Liquid
Cylinders: 1
Engine Disp. to Weight (cc): 0.57
Engine Size (cc): 84
Engine Size (ci): 5.2
Engine Stroke: 2-Stroke
Engine Type: Single-Cylinder
Fuel Capacity (gal): 1.4
Fuel Requirements: Premium
Number Of Carburetors: 1
Starter: Kick
Stroke (in): 1.93
Stroke (mm): 49
Valve Configuration: Reed Valve

Other Information

Decal Kit
Exhaust Guard
Exterior Covers
Exterior Guards
Foot Pegs
Foot Peg Location: Driver
Fork Guards
Front Fender
Hand Grips
Radiator Cover
Rear Fender
Stand
Stand Type: Kick

Specifications

Body Material: Plastic
Dry Weight (kg): 67
Dry Weight (lbs): 147
Front Tire (Full Spec): Maxxis Maxx Cross SI 70/100 R17 40M
Front Tire (Inches): 17
Front Tire Aspect Ratio: 100
Front Tire Speed Rating: M
Front Tire Width: 70
Front Wheel Width (in): 1.4
Fuel Capacity (liters): 5
Ground Clearance (in): 13.2
Ground Clearance (mm): 336
GVWR (kgs): 75
GVWR (lbs): 165
Rear Tire (Full Spec): Maxxis Maxx Cross SI 90/100 R14 49M
Rear Tire (Inches): 14
Rear Tire Aspect Ratio: 100
Rear Tire Speed Rating: M
Rear Tire Width: 90
Rear Wheel Width (in): 1.6
Seat Height (inches): 34
Tube / Tubeless: Tubed
Wheelbase (in): 50.8
Wheelbase (mm): 1290
Wheels Composition: Aluminum
